HY-1800ML 1.8m Eco-Latex Printer
The HY-1800ML is a 1.8 m eco-latex printer built around 3 or 4 Epson i3200-A1 heads, printing White + Color + OP varnish in one pass with LED curing. It runs 15 m²/h (3-head) to 25 m²/h (4-head) at 4-pass and handles leather, PU, PVC, TPU and canvas up to 20 mm thick with low-odor eco-latex ink.
Overview
The HY-1800ML is a 1.8 m eco-latex printer built around 3 or 4 Epson i3200-A1 heads with W + Color + OP one-pass output and LED curing. It targets leather, PU, PVC, TPU and canvas substrates - applications where solvent or UV ink would be either too harsh or too slow to cure on flexible non-textile media.
Key features
- 3-head or 4-head Epson i3200-A1 configurations - 15 m²/h (4-pass, 3-head) to 25 m²/h (4-pass, 4-head).
- W + Color + OP one-pass output - white underbase, color and over-print varnish / primer in a single pass.
- LED curing for low energy consumption and gentle drying on heat-sensitive materials.
- High-precision belt drive with vacuum-belt feeding handles non-stable substrates (PU, TPU) without skew.
- Anti-collision carriage and ink-level alarm for unattended long-run production.
- 20 mm media thickness supports rigid sheets and stacked layers.
Materials
- Leather / PU - apparel, accessories, automotive interior
- PVC sheets - banners, signage, industrial labels
- TPU films - sportswear panels, accessories
- Canvas / fine-art canvas - décor and art reproduction
For non-absorbent or low-surface-energy materials, apply a dedicated primer or surface treatment per the material supplier’s TDS.
Who it’s for
Leather goods producers, sign shops, sportswear panel manufacturers and contract printers running mixed flexible-substrate orders that need environmentally friendly ink chemistry and one-pass color + white + varnish.
For UV-cured printing on rigid substrates (glass, metal, wood) see the HY-6090 UV flatbed printer. For direct-to-fabric textile R2R, see the H-Series R2R printers.
Factory-direct manufacturer · OEM / ODM · in-house R&D and after-sales support
Why Choose H·EASY Latex Printing
i3200-A1 platform · 3/4 heads for flexible expansion
3-head / 4-head layouts scale from sampling to volume.
Belt-drive conveyor · stable long-run printing
Belt-drive conveyor keeps media tracking straight for long jobs.
Professional feeding system
Professional feeding stabilizes tension for fabrics and soft films.
White + Color + OP synchronized output
White + Color + OP in one pass for opaque, durable results on dark / non-porous media.
Intelligent & safe operation
Ink-level alarm and anti-collision carriage reduce unplanned downtime.
Eco-friendly latex ink
Eco-latex ink with LED curing assist for low-odor production.
Engineered for production
Throughput & quality · 3H/4H options, 720×1800 dpi
- 3-head layout: 4-pass ≈15 m²/h; 6-pass ≈12 m²/h.
- 4-head layout: 4-pass ≈25 m²/h; 6-pass ≈20 m²/h.
- 720×1800 dpi resolution ensures clean text edges and crisp textures, ideal for leather and faux-leather patterns.
Media handling · belt drive + professional feeding + ≤20 mm thickness
- Belt-driven vacuum feed ensures straight tracking for large-format media.
- Professional feeding system for fabrics and sheets minimizes wrinkles and tension fluctuations.
- Maximum media thickness ≤20 mm, suitable for leather, PVC, TPU, canvas, and similar substrates.
Where H·EASY HY-1800ML Excels
Wide-format graphics and décor on leather, PVC, TPU, canvas and soft signage media.
HY-1800ML Specifications
| Specification | HY-1800ML |
|---|---|
| Print width | 1800 mm (1.8 m) |
| Printheads | Epson i3200-A1, 3-head or 4-head configurations |
| Speed (3-head) | 4-pass 15 m²/h · 6-pass 12 m²/h |
| Speed (4-head) | 4-pass 25 m²/h · 6-pass 20 m²/h |
| Resolution | 720 × 1800 dpi |
| Ink | Eco-latex ink (low odor, environmentally friendly) |
| Channels | W + Color + OP (white + color + over-print varnish/primer) in one pass |
| Curing | LED curing light |
| Media thickness | Up to 20 mm |
| Feed system | High-precision belt drive with professional fabric / roll feeding |
| Machine size (L × W × H) | 3500 × 900 × 1500 mm |
| Weight | 1100 kg net |
| RIP software | RIIN / Maintop / PhotoPRINT / ColorGATE / ONYX |
| File formats | BMP / TIFF / EPS / PDF / AI / JPEG |
Compare Related H·EASY Printers
H·EASY Technical Support
One-year warranty (extendable)
Standard 12-month coverage on the core machine, with optional 24/36-month extended care.
Installation & onboarding
Step-by-step video and PDF guides for setup, calibration and your first print.
Knowledge base & troubleshooting
Quick guides for common issues, with checklists and fixes.
Online remote guidance
Engineers provide real-time diagnosis and tuning via WhatsApp, Zoom or AnyDesk.
